Applications

Critical Sanitary Support

Permacote® is designed for diverse electrical and mechanical installations including food and beverage, pharmaceutical, consumer goods manufacturing plants, and cosmetic production applications—any application where sanitary safety is critical.

Permacote® is also ideal to support conduit and process piping where high load ratings are important.

Robroy Hygienic™ Symbol

Permacote® products marked with the Hygienic logo indicate that the installed product has been reviewed and listed to both electrical and hygienic standards, as applicable. Products marked with the Hygienic logo add a visual indication of the use of a product designed and tested for use in hygienic/sanitary installations. In addition to the Hygienic logo, those products will also be marked with the electrical certification and Hygienic certification logos.

Learn More

NSF Certification

Recognized by regulatory agencies at the local, state, federal and international level, NSF certification demonstrates that a product complies with all standard requirements. NSF conducts periodic facility audits and product testing to verify that the product continues to comply with the standard. The NSF mark is your assurance that the product has been tested by one of the most respected independent certification organizations in existence today. It is valued by consumers, manufacturers, retailers and regulatory agencies worldwide. Robroy Industries ROCKET RACK Products have been tested and certified under the Food Safety and Quality Product/System Category to standard NSF/ANSI/3-A 14159-1.

NSF

Configurations

Whether you are looking for a solution for sanitary environments or looking for a faster and safer solution to reduce installation time, Permacote’s many benefits provide a utility agnostic system which can be used with electrical, mechanical or process piping.

Configuration Features

Configurations for hygienic applications are designed so that there are no flat surfaces, instead using slopped designs.
The patented Permacote® slot design and custom hardware eliminates harborage points because there are no recessed spaces or exposed threads.
Easily adaptable to plan changes due to the patented slot design, also allows for additional conduit/piping in the future.
Additional safety provided by Radius corners provide additional safety features.
Oxidative Thermo Process Labels remove risk of contamination by foreign matter, unlike traditional sticker labels.
Hardware is specially designed for form-fit-function to maximize hygienic requirements.
Blue (non-food color) FDA compliant silicone gaskets.

Rack Types

Rack Types
Configuration by Rack Type	Where Used?	Material & Size
Tented	Food Zone Areas where horizontal trapeze hygienic install is required, or post mount rack system is desired.	304SS, AL(2" or 3" x ¼")12", 18", 24", 30", 36", 48"
Standard	Where horizontal trapeze mounting of heavier load ratings is required and/or flat surface area is required to support infrastructure integrity.	304SS, AL(2" or 3" x ¼")12", 18", 24", 30", 36", 48"
Flat	Food Zone Areas where horizontal trapeze hygienic install is required, or post mount rack system is desired.	304SS, AL(2" or 3" x ¼")12", 18", 24", 30", 36", 48"

Mounting Types

Configuration by Mounting Types
Mount Type	Where Used?	Material & Size (316SS custom)	Material & Size (316SS custom)
Trapeze	When mounting from ceiling in single or multi-tier configuration.	304SS or ZINC Plated Steel w/ PVC Encased Rocket Rod (6,') 3/8", 1/2" (12') 3/8", 1/2" Other sizes available: 1/4", 5/8", 3/4"	Tented Rack (w/ 3/8" or 1/2" hardware) Standard Rack (3/8" or 1/2" hardware separate)
Post	When a configurable platform structure or a custom framework for mounting equipment is required.	304SS hermetically sealed (2" post) w/ cap and foot 48", 60", 72", 78" 84", 96", 108", 120" Custom lengths available: Foot Options • Standard 4 x 6 x 1/4" w/ four 9/16" mounting holes • Roof Mount 6 x 12 x 1/2" w/ pad (no holes)	Post Tented Rack (w/ 2" U-bolt) 12", 18", 24", 30", 36", 48" Flat Rack (vertical only) (2" U-bolt hardware separate) Extension Arms (horizontal & vertical) (w/ 2" U-bolt)6.5", 10.5" slot
Wall/Surface	Provides a gasketed mounting stand-off system to surface mount plant infrastructure.	304SS Rocket Plate (just plate, 2" or 4" rod w/ two jam nuts) Rocket Spacer (5/16" or 7/16" hole) 1", 2", 4"	Flat & Flat Slot Only Rack (3/8" cap nut hardware separate) Individual Mount (Split Ring, Pipe Clamps, Process Hex Clamps)
